WebKit API Reference

The WebKit API is a series of uniVerse BASIC routines that can be used to process HTML forms or to dynamically generate HTML documents from data stored in a uniVerse database file. This is only a sample of the routines that are included in WebKit. The first set of functions are used to get and parse the information passed to a uniVerse program called by httpd, or to generate error output. The Tag functions generate HTML tag sequences.

Utility Functions

HTMLGetPostArgs Retrieve and parse HTML argument string.
HTMLGetArg Retrieve and parse individual arguments from the output of HTMLGetPostArgs.
HTMLCGIParse Parse the argument string generated from a HTML form.
HTMLCGIEncode Escape HTML metacharacters in a string to be displayed in an HTML document.
HTMLError Display a string in HTML format.

HTML Tag Generation

HTMLTagBody create a tag that opens or closes the body of a HTML document.
HTMLTagCheckBox create a CHECKBOX for a HTML document
HTMLTagFormPost create a FORM with the POST method for a HTML
HTMLTagHead create a tag that opens or closes the header of a HTML document.
HTMLTagHeader the function called for designating text as a HEADER in a HTML document
HTMLTagImage the function called for placing an IMAGE in an HTML document
HTMLTagLabel create a LABEL for a reference in an HTML document
HTMLTagLi create a LIST of text for a document
HTMLTagLink create a LINK for a HTML document
HTMLTagPassword create a PASSWORD input box for a HTML document
HTMLTagRadio create a RADIO button for a HTML document
HTMLTagReset create a RESET button for a HTML document
HTMLTagSelect create a SELECT list box with the items that are passed to it.
HTMLTagSubmit create a SUBMIT button for a HTML document
HTMLTagStrong the function called for designating text as STRONG text for a HTML document
HTMLTagTable create a table for an HTML document
HTMLTagTextArea create a TEXT AREA for a HTML document
HTMLTagTextInput create a TEXT box for input in a HTML document
HTMLTagUl create an unordered list tag for a list in a document.

HTMLGetPostArgs

Retrieve arguments from the command line. The WKAPI assumes that any post arguments in standard in are extracted and put on the command line. Most commonly used for retrieving arguments from an HTML form. HTMLCGIParse is called from HTMLGetPostArgs.

HTMLGetPostArgs first looks for input in standard in, where it would be put by httpd in response to a form submitted with POST method. It then looks for input on the command line. This feature can be used to debug routines designed for POST forms without having to run a browser.

Syntax

variable=HTMLGetPostArgs(dummy)

dummy: HTMLGetPostArgs needs an argument passed to it but it does not matter what is contained in that variable

HTMLGetPostArgs looks in the VOC for a record named HTML.TRACE.IP. If the record exists, and the IP address in that record matches the IP address of the client invoking this routine, HTMLGetPostArgs saves the current command line in a VOC entry named HTML.LAST.CMD. This is useful for debugging routines without having to involve a browser and the httpd. To use RAID to debug the routine, edit HTML.LAST.CMD and insert -DEBUG as the first parameter, and HTMLGetPostArgs will enter the debugger just before returning to the calling routine. Back to Index

HTMLGetArg

Retrieve specific arguments from the string generated by HTMLGetPostArgs. Arguments can be retrieved by name or by position in the argument string.

Syntax

variable=HTMLGetArg(name,argstring)

or

variable=HTMLGetArg(n,argstring)

argstring: argstring is the string of arguments passed by httpd from a POST method form. It contains arguments of one of two forms: gname or name=value separated by "&" characters.
name: name is the name from the name option of the HTML form tag. If the argument is passed as just a name (e.g., a checkbox tag), then HTMLGetArg returns the argument name. If the argument is a name=value pair, HTMLGetArg returns the value. If the specified argument is a muliple selection list, then HTMLGetArg returns all values separated by "&" characters.
n: the integer position of the argument to be returned. HTMLGetArg returns either the name or name=value.

HTMLCGIParse

CGIParse replaces CGI escape sequences with the original characters.

Syntax

variable=HTMLCGIParse(string)

string: The text from an HTML form to be parsed.

HTMLCGIEncode

CGIEncode substitutes the appropriate escape strings for HTML metacharacters.

Syntax

variable=HTMLCGIEncode(string)

string: The text to be parsed for display in an HTML document.

HTMLError

Returns an Error message that has the name of the program originally called followed by the specified text.

Syntax

variable=HTMLError(Text)

Text: The text to be displayed in the Error message.

HTMLTagBody

Generate a tag specifing the beginning of the body of an HTML document

Syntax

variable=HTMLTagBody(StartorEnd)

StartorEnd: If StartorEnd="START" then an open tag <BODY> is produced; any other value will produce a close tag </BODY>

HTMLTagCheckBox

Generate a CheckBox control in a form

Syntax

variable=HTMLTagCheckBox(name,value,checked)

name: the name to given to the checkbox tag. name is required
value: value to passed back as value of this control if the checkbox is checked. If value is specified as the null string, the value passed back by the browser is "CHECKED"
checked: if checked is not the empty string then the CHECKED option is set.

HTMLTagFormPost

Generate a form tag using post as the method

Syntax

variable=HTMLTagFormPost(action)

action: the action to be carried out when the form has been submitted. action is require.

HTMLTagHeader

Generate text to be displayed as a header.

Syntax

variable=HTMLTagHeader(text,value)

text: the text to be displayed as a header. text is required
value: the degree of prominence of the header (1 being the greatest, 6 being the smallest). If no value is given for value, (1) is the default.

HTMLTagImage

Places an image in the document.

Syntax

variable=HTMLTagImage(imagefilename,align)

imagefilename: the name of the file that contains the image to be displayed. imagefilename is required.
align: the alignment of the image (left, center, or right are the values). If no value is given for align, then (left) is the default.

HTMLTagLabel

Generate a label anchor.

Syntax

variable=HTMLTagLabel(label)

label: label is the text used as a the label for a link to reference. label is required

HTMLTagLi

Generate a tag for building a list item for a ordered, unordered, menu, or directory list.

Syntax

variable=HTMLTagLi(text)

text: text is the text used in the list.

HTMLTagLink

Generate a link anchor that references a label or a URL.

Syntax

variable=HTMLTagTagLink(text,reference)

text: the text to be used as the link(or anchor). text is required
reference: the URL orlabel that is to be referenced when the anchor is activated. reference is required.

Any HTML entities in the text are converted to the HTML escape sequences. Back to Index

HTMLTagPassword

Generate a password input box control in a form.

Syntax

variable=HTMLTagPassword(name,value,size)

name: the name given to the password input. name is required
value: the default value for the password input box.
size: the size(width) of the password input box. If no value is given, (15) is the default

HTMLTagRadio

Generate a Radio button control in a form.

Syntax

variable=HTMLTagRadio(name,value,checked)

name: the name given to the radio button tag. name is required
value: the value passed back as the value of this control is the button is activated. If value is specified as the null string, the value passed back by the browser is "CHECKED"
checked: if checked is not the empty string then the CHECKED option is set.

HTMLTagReset

Generate a Reset button in a form.

Syntax

variable=HTMLTagReset(value)

value: the text to be displayed on the face of the button (e.g., Reset, Clear). If no value is given,("Reset") is the default.

HTMLTagSelect

Generate a select list box for a document.

Syntax

variable=HTMLTagSelect(name,items,size,multi,selected)

name: the name given to that control
items: items is a dynamic array containing the list box values separated by @FM
size: size is an interger value representing the number of items (or options) that will be displayed at one time. If no value is given for size, then (3) is the default.
multi: If multi is 1, then HTMLTagSelect produces a list box that can have multiple selections. You can use the EQUATED value of MULTIPLE.SELECT
selected: To have HTMLTagSelect generate some of the options as selected by default, place the items to be selected into selected. If this is a multiple selection list, and you want to select more than one item, selected should contain the items separated by field marks. If there is more than one selected item, multi must be set to MULTIPLE.SELECT.

HTMLTagSubmit

Generate a Submit button in a form.

Syntax

variable=HTMLTagSubmit(value)

value: the value is what is displayed on the face of the button (e.g.,: OK, Submit). If no value is given,("Submit") is the default.

HTMLTagStrong

HTMLTagStrong generated the tags for text to be displayed as strong (bold).

Syntax

variable=HTMLTagStrong(text)

text: the text to be displayed with as bold. text is required.

HTMLTagTable

HTMLTagTable generates an HTML Table from the data passed to it.

Syntax

variable=HTMLTagTable(Options,Caption,TableData)

Options: table attribute values delimited by @FM, empty values are defaulted
BORDER @FM CELLSPACING @FM CELLPADDING
BORDER default is 1, CELLSPACING default is 2, CELLPADDING default is 1
Caption: The caption text and alignment attributes separated by @FM.
caption text@FMalignment
where alignment is the string TOP or BOTTOM
TableData

HTMLTagTextArea

Generate a text area.

Syntax

variable=HTMLTagTextArea(name,text,rows,cols)

name: the name given to the text area. name is required
text: the text to be displayed inside the text area.
rows: the height of the text area. If no value is given, (3) is the default.
cols: the number of columns (or the length) of the text area. If no value is given , (50) is the default.

HTMLTagTextInput

Generate a text input box in a form.

Syntax

variable=HTMLTagTextInput(name,value,size)

name: the name given to the control. name is required
value: the default value of the text input box that will be displayed. If no value is given, (15) is the default.size; size is the width of the textinput box. If no value is given for size, (15) is used as the default.

HTMLTagUl

Generate a tag for an unodered list.

Syntax

variable=HTMLTagUl(StartorEnd)

StartorEnd: if StartorEnd has a value of TAG.START then the a tag for opening an unordered list is produced, any other value produces a tag for closing an unordered list.

Written by Matt Cornell (mcornell@mmcis.com), 9/6/94, maintained by Charles Cornell (cac@mmcis.com)
